Hood

Product Highlight

Double Power System

BLDC Motor

Powerful upgrade that further enhances the smoke extraction capability unrestrained airflow 1,400 m3/h, increase air pressure up to 850Pa

BLDC Motor

Turbo System

Increase extraction power for 100 seconds, leading grease and smoke out of the kitchen smoothly.

Turbo System

Smart Smotion (Smoke + Motion) Detection

Hand wave control

Wave to switch on or switch off the hood (turbo and light)

Hand wave control

Patented Wing-like Surround Suction Plate

Wing-liked surround suction plate act as a barrier between wok and filter, ensure no oil dripping compare to normal aluminum grease filter. It is effective in capturing cooking smoke

Patented Wing-like Surround Suction Plate

Effective Oil Filtration Rate

Effective Oil Filtration Rate

Effective Aluminium & Carbon Filter

High Efficiency Filter technology is a must in any recirculation hood to maintain a clean and fresh kitchen, otherwise greasy fumes will linger no matter how great the hood's suction power is. Normal recirculation hoods are unable to filter cooking smoke completely, as they tend to drift back to the kitchen via the hood's outlet.

Effective Aluminium & Carbon Filter

'Shark Fin' Air Guide

114° angle 'shark fin' air guide to redirect the air flow so that turbulence generated from direct rebounding of an unguided airflow can be avoided.

'Shark Fin' Air Guide

Humanized Design

Filter Replacement Notification

When the hood has operated up to 150-450* hours, a cleaning signal will be displayed, alert user to change the carbon filter.
*Turbo / High speed – 150 hours, Lowest speed – 450 hours

Filter Replacement Notification

Quiet Operation

Multiple noise-reduction technologies make you cook at peace. Noise level produced is as low as 41dB

Quiet Operation
Specifications
Certification
CB,SIRIM
Type of Motor
Brushless DC Inverter Motor
Material of hood
90cm wide stainless steel with black panel surface design
Unrestrained airflow (m3/hr)
1400
IEC airflow (m3/hr)
920
Motor Power (W)
294
Max Static Pressure (Pa)
850
Noise Level (dB)
53
No. of Speeds Fan Control
3 + Turbo
Illumination Power in LED (W)
3W x 2
Type of hood
Chimney hood
Oil Filtration Rate
96%
Odor Reduction Rate
NIL
Automatic Turbo System
NIL
Smart Smoke and Sound Detection
NIL
Intelligent Air Management
NIL
Anion Sterilisation
NIL
Delay Off Function
YES
Control Mode
Touch + Wave
Type of Filter
Corrugated Filter
Special Features
NIL
Power Supply
240V/50hZ
Dimension W x D x H (mm)
895 x 522 x (566-905)
IEC
